TP-Link 24 Port 10100Mbps + 2 Port Gigabit Unmanaged PoE+ Switch 8TP10294505

Product Description

Compliance with the 802.3afat PoE+ standard supports up to 30 W on each PoE port. The total 250 W PoE power budget for the 24 PoE ports makes it has wide range of applications, such as surveillance, offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and etc.

With extend mode, the PoE transmission distance reaches up to 250 m*perfect for IP Camera deployment in large areas.
*The speed of the ports in extend mode will downgrade to 10 Mbps. Actual transmission distance may vary due to cable quality.

Priority Mode and Isolation Mode make surveillance smoother and safer, with dedicated design for IP surveillance

2 Gigabit RJ45 ports and 2 combo gigabit SFP ports ensure smooth streaming even when 24 HD IP cameras work simultaneously.

Durable metal casing and professional heat dissipation design ensure the wide operating temperature (0-50?) with reliability.

1. 24x PoE+ 10/100 Mbps RJ45 ports, 2x Gigabit RJ45 ports, and 2x combo Gigabit SFP slots
2. High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports
3. Up to 250 m data and power PoE transmission range under Extend Mode, ideal for surveillance system
4. Priority Mode ensures high priority of ports 1–8 to guarantees the quality of sensitive applications like video monitor
5. Isolation Mode allows one-click client traffic separation for higher security and performance
6. Plug and play, with no configuration and installation needed

1. Manufacturer:  TP-Link
2. Type:  Ethernet Switches
3. Data Rates:  10/100Mbps
4. Dimensions:  440x180x44mm
5. Number of Ports:  24 Ports
6. Brand: TP Link
7. Pack Size: 1
8. Parcel Dimensions: n/a
9. TP Link Reference: 8TP10294505
10. EAN/UPC Number: 6935364089450
11. Datasheet: Download Datasheet
12. Install Guide: Download Install Guide
